| Processor |
 Support
Intel® Pentium® M Processor Up to 1.7GHz
Support
400MHz System Bus |
| Core
Logic |
Intel®
855GME + ICH4 |
| Cache |
1MB
On-Die L2 Cache for Pentium® M Processor |
| Memory |
256MB
on Board, Expandable to 768MB with optional 256/512MB
One
Mini Micro Dim Slot Support DDR333 Memory |
| Display |
12.1"
XGA TFT Display with Resolution 1024X768 Pixel |
| Video
system |
Integrated
Intel 855MGE Video Controller
Up to 64MB
Video Share Memory with Intel® Dynamic Video
Memory Technology
4X AGP Architecture
Graphics Capability, 3D Graphic Supported
Support
LCD/CRT Simultaneous Display Mode |
| Audio
System |
AC'97
Audio System
Two
Stereo Speakers and One Microphone Built-in
External
Microphone-in Jack and Headphone-out Jack Built-in |
| Hard
Drive |
2.5",
9.5mm Height HDD, Enhanced IDE
Ultra DMA
66/100 Mode Supported
Optional
20 / 30 / 40 / 60 / 80GB Supported |
| Optical
Device |
9.5mm
/ 5.25" Height
Optional
2X / 24X / 10X / 8X / 24X DVD-RW Drive
Optional
24X / 24X / 16X / 24X DVD/CD-RW Comb Drive |
| Floppy
Drive |
Support
Optional External USB Floppy Drive |
| BIOS |
ACPI Compliance
/ Plug and Play Supported |
| PC
Card Slot |
One
Type II PCMCIA Card Slot with Cardbus Support
SmartMedia
Card Reader Slot |
| Communication |
Built-in
56K bps V.90/V.92 Fax Modem
Built-in
100Base-TX Ethernet Adapter
Optional
802.11b, a+g Wireless LAN Adapter |
| Pointing
Device |
Touch
Pad with Button |
| I/O
Ports |
Three
USB2.0 Ports / IEEE 1394 Port /
Kensington
Lock Slot
RJ45 Port
for Ethernet Card / RJ-11Port for Fax Modem
External
VGA Port / DC-Input
Port
Headphone-Out
Jack / MIC-in Jack |
| Battery |
24
WHr battery pack, 2.5 hrs run-down life*D
48 WHr battery
pack, 5 hrs run-down life*D
72 WHr battery
pack, 7.9 hrs run-down life*D
(*D The figure is based on Mobile Mark 2002 after activating
Power4 Gear power-saving technology. The battery life
subjects to different CPU and HDD) |
| AC
Adapter |
100-240V
50W Universal AC Adapter |
| Weight |
3.41lbs
(1.55kg) with 12.1" display, 24 WHr Battery and HDD |
| Dimension |
10.83"(W)
X 9.25"(D) X 1.17"(H) (275mm X 235mm X 29.8mm) |
| Accessory |
AC
Adapter / Manual / Driver CD-Title |
| Operating
System |
Support
Microsoft® Windows XP |
| Security |
System
Password Protection Supported by BIOS Setting
Kensington
Lock Slot
Optional
Notebook Security Guardian |
